Description
Thermino e - Designed to produce domestic hot water and is heated directly by grid electricity only. This can be used as a space saving and flexible alternative to a hot water tank with an immersion heater. When combined with a charge timer and a variable electricity tariff, the Thermino e range allows for low cost electric water heating. The reduced size combined with the fact that the Sunamp does not need any venting allows for full flexibility in install location.
The Thermino 70 ePV would typically be installed in a studio apartment, or for off-grid applications in a caravan or boat.
Note, the Sunamp is very heavy:
- Tilting it beyond 45 degrees may damage the unit and void your warranty.
| Power Inputs: |
Grid electricity |
|
|
Boiler
|
|
|
Solar Panels
|
|
|
Heat Pump |
General Specifications
| Product Code |
SGP-AAW-AVZ-1
|
| Equivalent energy storage |
3.2kWh |
| Equivalent hot water capacity |
74L |
| Water available at 40°C |
105L |
| Weight in use |
79kg |
| Height |
440mm |
| Width |
365mm |
| Depth |
575mm |
| Storage core warranty |
10 Years |
| Other parts warranty |
2 Years |
Technical Specifications
| Standing heat loss |
20W |
| Energy efficiency rating |
C |
| Recommended flow rate |
6LPM |
| Minimum supply pressure |
1.5 bar |
| Maximum supply pressure |
10 bar |
| Annual electricity consumption |
542kWh/annum |
