Description
The multiple award winning range of Ultra Quiet AA chassis Ecodan monobloc air source heat pumps are designed specifically to suit the demands of the UK market. These units can be cascaded with up to 6 other identical units to provide up to 84kW of heat output.
The innovative, stylish and compact single fan outdoor unit utilises advanced technologies to deliver improved efficiencies. Designed for a wide range of applications, the market leading low noise levels virtually eliminate the need for planning permission, maximises installation options and is a viable solution for all types of domestic requirements that the UK housing market demands.
The Ecodan comes with a range of compatible storage tanks in a range of capacities; pre-plumbed or packaged.
Key Features
- Self-contained unit, only requiring water and electric connections
- No need for gas supply, flues or ventilation
- Low maintenance and ultra quiet operation
- Operates with outside temperatures as low as -28°C
- Optimised low ambient defrost control and operation down to -15°C
- Hybrid function, for use with conventional boilers
- Energy monitoring as standard
- Multiple unit cascade function
Standalone Kit Includes:
- WIFI Interface
- Flow and return water temperature thermistor
- DWH water temperature thermistor
- Magnetic Filter
- Insulated flexible connection pipes
- Flow sensor
Technical Information
| Product number |
PUZ-HWM140VHA(-BS)
|
|
| MCS listed SCOPs |
|
| @35°C |
4.33
|
| @40°C |
4.05
|
| @45°C |
3.77
|
| @50°C |
3.51
|
| @55°C |
3.26
|
|
| Heating nominal capacity |
14.0kW |
| Compressor type |
Scroll
|
| Refrigerant Type |
R32 |
| Refrigerant Volume |
3.3kg |
| Nominal flow rate |
40.1L/m |
| Minimum water content |
20L |
|
| Heating up to |
55°c |
| Min operating temperature |
-20°c |
| Max operating temperature |
35°c |
| Electricity Supply |
220-240V |
| Sound Power Level |
67dBA |
|
| Height |
1020mm |
| Width |
1050mm |
| Depth |
480mm |
| Net Weight |
132kg |
|
| Warranty |
Min 3 years |
