PRODUCT FEATURES
- High performance version of the seventh-generation IQ platform
- Smart-Grid ready
- Easily integrated with the Gateway-S™ and Enphase™ monitoring and analysis software
- Easy to install thanks to lightweight design and improved two-wire cabling
- Double insulated housing, protection class II
- Modular design allows simple expansion of system as required
- Ultra reliable – system keeps working even if a single panel/microinverter fails or panel slips into shade
- Mobile app allows enhanced control and monitoring possibilities
PRODUCT SPECIFICATION
- Commonly used module pairings: 295W - 460W +
- Module compatibility: 60-cell/120 half-cell and 72-cell/144 half-cell PV modules
- Peak output power: 366 VA
- Operating range: 18V - 58V
- IP Rating: IP67
- Weight: 1.08 kg
- Rated Power: 500 W
- Min PPT Voltage: 38 V
- Max PPT Voltage: 43 V
- DC Startup Voltage: 33 V
- DC Shutdown Voltage: 32 V
- Max Input Voltage: 58 V
- Max DC Power: 500 W
- Max AC Power (5 Minutes): 366 W
- Surge AC Power (1 Second): 349 W
- Max DC Current: 10.2 A
- Max DC Inputs: 1
- Has DC Fuses: 0
- Connector: MC4
- Included Connectors: 0
- Euro Efficiency: 96.5 %
- Transformer: HF
- MPPT Quantity : 1
- Has Integrated DC Switch: No
- Warranty: 25 years
Enphase Energy, founded in 2006 in California, is the world leader in micro inverter technology with more than 13 million units sold worldwide and over 500,000 installed systems representing over 3GW of clean energy.
